Breathing pattern

Auxiliary / control:   A/C

Synchronous intermittent command:  SIMV

A \ C + sigh:   A/C+SIGH

Manual ventilation:  MANUAL

Spontaneous breathing:   SPONT

Noninvasive ventilation:  A/C+Continuous air flow

control section

Tidal volume:   50ml-1500ml

Breath ratio:  1:0.3、1:0.5、1:0.7、1：1、1:1.15、1:2、1:2.5、1:3、1：3.5、1:4

Respiratory rate:   4 times / min - 80 times / min

Pressure limit:   2KPa—6kPa

Starting pressure regulation:  -2KPa---2KPa

Continuous air flow:  3LPM—5LPM

Inspiratory pause:  20seconds

Inspiratory oxygen concentration: 48%--100%Adjustable

Pressure limit of safety valve:  6KPa±15%

Monitoring part

LCD display

Airway pressure waveform

Tidal intake

Minute ventilation

Total respiratory rate

Peak airway pressure

Departure instruction

AC and DC power tips

Battery level prompt

All parameters and waveforms can be monitored in manual ventilation mode:

Audible and visual alarm part

Insufficient air supply alarm

Upper and lower airway pressure alarm

Breakpoint alarm

Battery low pressure alarm

other

Power Supply:  AC100V—240V,50/60Hz

           12VVehicle power supply

           Built in battery >=2 hours

Air supply pressure:   280KPa—600KPa

Contact work of gas source of self provided gas cylinder:   >=30minute

Ventilator compliance:  <=4*10²-ml/100pa

Standard configuration

Multi functional mainframe rack:  1

Gas storage bottle:  1

Oxygen bridge:  1

Wrench:  1

Accessories and accessories package:  1

Optional

PEEP(0--1KPa）：  1

manipulator:  1

Instrument trolley:  1

Humidifier:  1
