Tianjin guyufan Biotechnology Co., Ltd

Sample   capacity

48*0.2ml

Applicable   consumables

8*0.2ml   row tube, 0.2ml single tube

reaction   system

10-120ul,   support fast response mode system

Heating/cooling   module

Semiconductor   thermoelectric module

Temperature   control range

4-100°C

Maximum   heating rate

>3.5°C/s

Maximum   cooling rate

<3°C/s

Temperature   control accuracy

<±0.1°C

Temperature   uniformity

<±0.2°C(normal   type)、<±0.1°C(High   resolution)

Number   of temperature control areas

More   points (3 points)

Number   of gradients

3

Gradient   temperature range

0°C--20°C

Gradient   hole number

>12   A

Laser   origin

Maintenance-free   halogen lamp or xenon lamp

Laser   wavelength range

400-1000nm

Detection   components

Cold   low temperature CCD

Number   of detection channels

Standard   2-4 channels (6 channels in total, other options)

Applicable fuel and probe

FAM/SYBR   Green 1,VIC/HEX/TET/GY3,ROX/Texas Red,cy5,TAMARA

Software   function

Fluorescence   quantitative PCR system software

Real-time   amplification reaction curve function

Real-time   response curve display of specific specimens

Data   analysis function

Automatic   judgment of Yin and Yang results

Graphical   display function

noise

<50   dB

Electronic   hot cover

Automatic   pressure regulation
